7-inch MustHD 1024x600 HDMI Affordable On-camera Field Monitor with Focus Assist with Color Peaking (M700H)
The M700H is designed for the video enthusiast who needs an affordable field monitor. The M700H panel has vibrant colors and a wide viewing angle. To help insure correct focus and exposure it also has color peaking and false color functions. Several other features are a zoom function from 10% to 90% and display marker to show aspect ratios.
Major Features:
* 7" on-camera monitor with IPS screen
* Resolution 1024*600, support up to 1920x1080
* HDMI input/output
* Focus Peaking (RGB)
* False Color
* Exposure
* Aspect
* Over-scan
* Pixel to Pixel
* Black and White
* Zoom
Specifications:
| LCD | Size | 7 inches |
| Resolution | 1024*600, support up to 1920x1080 | |
| Pixel Pitch | 0.15（W）x0.15(H)mm | |
| Color Depth | 16.7M (8bit) | |
| Viewing Angle | H: 170 degrees ; V: 170 degrees | |
| Luminance | 300 cd/㎡(Center) | |
| Contrast Ratio | 800:1 | |
| Display Area | 153.6 (H) x 90 (V)mm | |
|
Input Signal |
HDMI | 480i/480p576i/576p/720p/1080i/1080p@60fps |
| Component | 3xRCA | |
| Composite | 1xRCA | |
| Output Signal | HDMI | 480i/480p576i/576p/720p/1080i/1080p@60fps |
| Audio Out | Analog Stereo(phone jack) Internal speaker (Mixed Mono) |
|
| Power | DC 6-20V | |
| Power Consumption (Approx) | < 8 Watts (typical) | |
| Operating Temperature | 0℃to 45℃ (32℉ to 113℉) | |
| Storage Temperature | -20℃to 60℃ (14℉ to 140℉) | |
| Main Body Dimension (mm) | 198x147.5x33.6 mm | |
| Weight | 0.48kg | |
| Accessories |
1. Sun-hood (detachable) 2. AC adaptor (US/EU/UK/AU) 3. User manual 4. External Self-define function button plate 5. Screws(for fixing the battery plate more tightly) 6. HDMI cable (Mini HDMI to HDMI) 7. Battery Plate-F970 8. Battery Plate-LP-E6(optional) 9. Battery-D28S(optional) 10. Carrying bag(optional) |
|
